| Description | Side Floor Kit For Use with Cargo Drawers. Featuring a sleek design, high-quality components, and the ability to create a fully customized system tailored to your requirements, the Outback Solutions range is the answer to all of your storage needs. |
Completely modular, the Outback Solutions range of drawer systems can be individually tailored to your needs and vehicle. Exclusive to ARB and suitable for many vehicles including wagons, utes (including extra cab), and trailers, this system can also be used in non-vehicle applications such as sheds and warehouses. Three types of modules are available in a range of sizes, resulting in more than 200 possible configurations.
| Side Floor Kit For Use with Cargo Drawers. Featuring a sleek design, high-quality components, and the ability to create a fully customised system tailored to your requirements, the Outback Solutions range is the answer to all of your storage needs. | Completely modular, the Outback Solutions range of drawer systems can be individually tailored to your needs and vehicle. Exclusive to ARB and suitable for many vehicles including wagons, utes (including extra cab), and trailers, this system can be used in non-vehicle applications such as sheds and warehouses.
Three types of modules are available, in a range of sizes, resulting in more than 200 possible configurations, all backed by a two-year warranty.
ARB “Outback Solution” Roller Drawers, Cargo Barriers, Child Restraint Anchorages are crash-tested and compliant to ADR (safety requirements) AS/NZS (Partial Cargo Barriers) ADR (Seats and Seat Anchorages) ADR (Child Restraint Anchorages).
FEATURES
- Engineered for both on and off-road touring with anti-rattle design
- Key lockable, push-pull slam shut latches for ease of use and maximum security
- Long-lasting, UV stable commercial carpet designed to complement modern vehicle interiors
- Cross folded floor ensures maximum support for items placed within each unit. Up to a Maximum of 150Kg per drawer, 300kg combined
- Fully Sealed, Dust and water-resistant bearings for superior longevity working in harsh environments
- Integrated fridge slides on roller floor models. Provides and always a flat surface
- Vehicle specific side floor kit with easy latches completes installation and provides additional storage areas within the cabin or tray
- Water-resistant bonded marine ply with steel reinforced guards for superior strength sourced from sustainable forests
- Folded stainless steel bearing runners for ultra-smooth drawer and slide operation
- Self-locking anti-rollback system locks into place at full extension, this holds the drawer from rolling closed even on inclines
- Modular units allow greater flexibility if needs change in the future
- Class-leading deep drawers with internal heights up to 250mm for greater packing potential
SPECIFICATIONS
- 304 grade brushed stainless steel
- Stainless steel mount rails
- Easy clean surface
- Does not interfere with current storage space
- Easy DIY setup for either home or fitting bays
- 8kg weight limit
- Rounded corners for reduced sharp points.
- *Not Compatible with Roller Floor Roller Drawer modules
- Stainless steel hardware.
- Adjustable Nylon runners.
- Compatible with ARB & Outback Drawers manufactured from 2010.
- RDTAB1045 suits RD1045
Table Surface.
RDTAB1045 = 499mm (L) x 472mm (W) x 19mm (H)
| Completely modular, the Outback Solutions range of drawer systems can be individually tailored to your needs and vehicle. Exclusive to ARB and suitable for many vehicles including wagons, utes (including extra cab), and trailers, this system can be used in non-vehicle applications such as sheds and warehouses. Three types of modules are available, in a range of sizes, resulting in more than 200 possible configurations. | |
| Content | | SIDE FLOOR
The vehicle-specific side floor kit fills in the area between the outer edge of the drawer and the side of the vehicle. The side floor completes the floor and provides a larger flat top surface while maintaining access to the wheel arch storage areas.
Each side floor kit contains both left and right-hand side floors. Stainless steel locking tabs locate and retain one end of the removable floor section, while the other end is attached with a simple push-to-close latch. A single lever disengages the latch for floor removal. The combination of stainless steel tabs and a straightforward latch results in a very easy-to-use and secure storage area.
Side floors are compatible with Roller Drawer modules and with Roller Floor modules when combined with a side floor adaptor. | | |
- Vehicle-specific side floor kit fills in the area between the outer edge of the drawer and the side of the vehicle.
- The side floor completes the floor and provides a larger flat top surface while maintaining access to the wheel arch storage areas.
- Each side floor kit contains both left and right hand side floors.
- Stainless steel locking tabs locate and retain one end of the removable floor section.
- The other end is attached with a simple to use push-to-close latch.
- A single lever disengages the latch for easy floor removal.
- The combination of stainless steel tabs and a simple straightforward latch results in a very easy-to-use and secure storage area.
- Side Floors are compatible with Roller Drawer modules and with Roller Floor modules when combined with a side floor adaptor.
| |
| Additional information |
| Weight |
8 kg |
| Dimensions |
62 × 26 × 14 cm |
|
| Weight |
6 kg |
| Dimensions |
90 × 20 × 24 cm |
|
| Weight |
6 kg |
| Dimensions |
90 × 20 × 20 cm |
|
| Weight |
37 kg |
| Dimensions |
76 × 52 × 9 cm |
|
| Weight |
7 kg |
| Dimensions |
62 × 28 × 20 cm |
|
| Weight |
10 kg |
| Dimensions |
80 × 35 × 14 cm |
|
